Single Ram 1500 CV Axle Shaft Assembly for 4WD Front
✔️ Front left/right 4WD; axle nut; 29/33 splines; optional boot

This CV axle shaft assembly is designed for front-end installation on Ram 1500 2012-2020 4WD and 1500 Classic 2019-2020 4x4, delivering power from transmission to wheels with a durable boot option for longevity.

✅ Location: Front Left or Right (Driver or Passenger Side)
✅ Axle Nut Included: Yes
✅ Spindle Nut Thread Size: M24 x 2.0
✅ Compressed Length: 24.37 in (619 mm)
✅ Input Shaft Spline Count: 29
✅ Output Shaft Spline Count: 33
✅ ABS Ring Included: No

💡 What is a CV axle shaft used for in a pickup? This component transfers power from the transmission to the drive wheels and supports steering and suspension movements in 4x4 setups.

- Transmits torque from transmission to wheel hub to drive vehicle - Absorbs steering inputs and bumps through CV joints - Uses protective boots to seal dirt and moisture and extend life
